UHF RFID Industrial Printer

This is an industrial-grade Ultra-High-Frequency (UHF) RFID printer designed for efficient, high-quality label printing and integrated RFID encoding. Combining industrial durability and flexible connectivity, it supports secondary development to adapt to diverse business scenarios.

UHF RFID Printer - Detailed Specifications

Parameter	UHF ZM2R/3R	ZM5R
Model	UHF ZM2R/3R	ZM5R
Dimensions (W×D×H)	310 × 208 × 195 mm	428 × 296 × 301 mm
Printing Method	Thermal Transfer / Thermal Sensitivity	Thermal Transfer / Thermal Sensitivity
Resolution	203 DPI (8 dots/mm)	300 DPI (11.8 dots/mm)
Print Speed	8 IPS (203.2 mm/s)	6 IPS (152.4 mm/s)
Print Width	4.25" (108 mm)	4.15" (105.6 mm)
Print Length	157.5" (4000 mm)	157.5" (4000 mm)
Display	/	128 × 64 Matrix FSTN display
Weight	2.62 KG	14.5 KG
Memory	8 MB Flash ROM, 16 MB SDRAM	8 MB Flash (Scalable to 16MB); 16 MB SDRAM (Scalable to 64MB)
Input Power Supply	24 VDC, 2.0 - 2.5 A	85 - 264 VAC, 47 - 63 Hz; Rated power: 150W
Paper Detection Direction	Movable reflective and penetrating dual sensors	Movable reflective and penetrating dual sensors
Label Roll Size	Width: max 4.5" (116 mm), min 0.8" (20 mm); Outer diameter: max 5" (127 mm); Inner diameter: min 1" (25.4 mm)	Width: max 120mm, min 20mm; Outer diameter: max 8" (203.2 mm); Inner diameter: min 1" (25.4 mm)
Label Thickness	0.06 ~ 1.5mm (0.002" ~ 0.06"), including backing paper; supports flexible metal - resistant labels	0.06 ~ 1.5mm (0.002" ~ 0.06"), including backing paper; supports flexible metal - resistant labels
Ribbon Size	Outer diameter (max): 2.75" (70 mm); Inner diameter: 1" (25.4 mm) or 0.5" (12.7 mm); Max width: 4.3" (110 mm); Max length: 300 m	Outer diameter (max): 2.76" (70 mm); Inner diameter: 0.5" (12.7 mm); Max width: 110 mm; Max length: 360 m

Hardware and Functional Features

Dual Model Options: Available in both an upright industrial-grade printer (left) and a desktop portable printer (right), catering to different printing needs (e.g., mass production/lightweight retail applications).
High-Speed, High-Resolution Printing: Equipped with an industrial-grade print engine, it delivers high-speed printing and crisp, clear outputs, ensuring sharp readability of text, barcodes, and graphics.
Multi-Interface Connectivity: Supports optional connections such as USB, serial port, and Ethernet ports, enabling seamless integration into existing IT infrastructures and multi-device collaboration.
RFID Integration Capability: Features BatchPrint/Encoding (batch printing and encoding), allowing simultaneous label printing and RFID chip data writing to streamline supply chain/Asset MANAGEMENT workflows.
Intelligent Paper Management: Includes an auto paper calibration function to automatically detect label length and position, minimizing manual intervention and preventing jams or misalignment.
Dual-Mode Printing Compatibility: Supports bimodal printing, accommodating a variety of label materials and specifications, such as RFID electronic labels and standard barcode labels, for use in retail, warehousing, logistics, and more.

Application Scenarios and Value

Whether for RFID anti-counterfeiting and inventory management in retail apparel, asset tracking in logistics and warehousing, or process workflow labeling in manufacturing, this RFID UHF printer enhances operational efficiency by integrating printing, encoding, and batch processing capabilities, enabling businesses to:

Read and write label data dynamically (supporting real-time updates);
Achieve end-to-end supply chain visibility (tracking from production to sale);
Optimize workflows and reduce costs (lowering manual effort and minimizing errors).

Additional Advantages

Secondary Development Support: Offers open interfaces and SDKs for deep customization, seamlessly integrating with proprietary management systems.
Durable Industrial Design: The upright model features a rugged housing for harsh environments like workshops and warehouses, while the desktop model is compact and portable, ideal for retail Stores and offices.

With its combination of high-speed printing, RFID encoding, multi-interface connectivity, and intelligent management capabilities, this RFID UHF printer serves as a core Tool for smart labeling in enterprise digital transformation, empowering retail, logistics, manufacturing, and other industries to achieve a holistic upgrade in efficient printing, accurate tracking, and anti-counterfeiting traceability.
