UHF RFID channel door gantry frame large warehouse asset inventory item entry and exit record management anti-theft machine

UHF RFID channel door gantry frame large warehouse asset inventory item entry and exit record management anti-theft machine

Frequency range: 860MHZ~960MHz
Identification method: (UHF RFID)
Material: 1.2mm thick carbon steel plate
Screen size: 21.5 inch capacitive screen
Reading time: 5-7 seconds for 1-500 tools
RFID main chip: Impinj R2000
Development support: SDK development kit
Working temperature: 0-60°C

It is mainly used for entry and exit management in logistics, warehousing and other scenarios, and plays the role of batch identification and anti-theft alarm.

Size: 3116mm*480mm*2996mm

Read and write function: support multi-label identification

Communication interface: network port

Machine power: 50W

RF protocol standard: ISO18000-6C (EPCC1G2)

Power input: 220V-50Hz

Development language: JAVA, C#

1. The multi-label reading ability is extremely strong, and the rate of missed reading and misreading is extremely low.

2. The antenna is specially designed, the Access Control coverage area is accurate, and there is no blind spot.

3. Built-in alarm light and buzzer

4. The placement distance of the RFID arched door is wider, and the maximum width can reach 5m.

5. An external monitor can be connected to display the information and quantity of passing items in real time, and can count the number of people entering and leaving.

UHF RFID channel door gantry frame large warehouse asset inventory item entry and exit record management anti-theft machine
